NovaStar MRV208-N Receiving Card – 256×256 Pixels | High‑Stability HUB75 LED Display Controller Board for LED Display Screens

$109.00
Package Qty
$109.00
$109.00
Shipping calculated at checkout.
999 in stock

Package Included

Version Package Included
MRV208-1 1 × MRV208-N Receiving Card
1 × User Manual

About this item

  • High-performance LED controller supporting HUB75E input and 8-port parallel RGB output
  • Up to 256×256@60Hz resolution, compatible with multiple LED module pixel pitches
  • Pixel-level Brightness & Chroma Calibration, 3D Support, Redundancy Backup for stable, high-quality display
  • High stability with 8 standard HUB75E connectors and EMC-compliant hardware
  • Compact and reliable, ideal for indoor/outdoor installations, rental LED screens, and creative LED setups

Order & Logistics

  • Lead Time: Typically ships within 2–5 business days
  • Packing: Cardboard box
  • Shipping: Orders in this series qualify for our Free Shipping Policy on purchases over $399. All products in this series are shipped directly from our headquarters warehouse（Standard Shipping: 9–18 days|Express Shipping: 5–9 days.）

Key Specifications

  • Input Ports: HUB75E x 8 (signal input/output to LED modules)
  • Output Ports: Supports up to 16 groups of parallel RGB data
  • Supported Resolutions: Up to 256×256 pixels @ 60Hz
  • Control Method: Network cable connection via sending card or controller
  • Power Supply: DC 3.3V (powered via LED display system)
  • Operating Temperature: –20°C to +70°C

Usage Notes / Installation Tips

  • Always power off the LED system before installing or removing the receiving card
  • Use shielded network cables for stable signal transmission
  • Ensure adequate ventilation inside the LED cabinet for prolonged operation
  • Keep away from static discharge sources; use anti-static protection when handling

Technical Specifications

Model MRV208-N MRV412-N MRV416-N
Loading capacity(pixel) 256×256 512×512 512×512
Max. parallel RGB data groups 16 24 32
Output Interface HUB75E×8 HUB75E×12 HUB75E×16
Max. Scanning 64 64 64
3D √ √ √
Pixel Level Brightness and Chroma Calibration √ √ √
18bit+ – √ √
Color Management – √ √
RGB Gamma Independent Adjustment – √ √
Low latency – √ √
Multi-batch Adjustment √ √ √
Temperature, voltage and communication status monitoring √ √ √
Redundancy Backup √ √ √
Configuration File Dual Backup √ √ √
Firmware Program Backup √ √ √
Firmware Program Read-back √ √ √
90-degree Multiple Rotation – √ √
Prestore Picture √ √ √
Support for 5-pin LCD √ √ √
Bit Error Testing √ √ √
Mapping √ √ √

Applications

  • Fixed LED billboards
  • Rental stage LED screens
  • Indoor/outdoor advertising screens
  • Conference / exhibition LED displays
