aClear Series Transparent LED Display Screen P3.91/7.81mm Pixel 1500nits/3500nits/5500nits in 1000x1000mm Aluminum Indoor Type for Glass/Window Display

From $14,043.00
Pixel Pitch
Brightness
Package Type
$14,043.00
$14,043.00
Shipping calculated at checkout.
Out of stock

aClear Series Transparent LED Display Screen P3.91/7.81mm Pixel 1500nits/3500nits/5500nits in 1000x1000mm Aluminum Indoor Type for Glass/Window Display

Self-adhesive Transparent LED Film Display Sample Kit

Package Included

Version Package Included
1 Square Meter Screen Only 1pcs of 1000x1000mm Screen Unit, Total 1 Square Meter
1 Square Meter Screen with Controller Box (Fixed Mounting) 1pcs of 1000x1000mm Screen Unit, and 1pcs of Novastar TB10 Plus Controller Box
1 Square Meter Screen with Controller Box (Hanging Mounting) 1pcs of 1000x1000mm Screen Unit, 1pcs 1Meter Hanging Rod, and 1pcs of Novastar TB10 Plus Controller Box

Order & Logistics

Lead Time: Standard production lead time: 2-5 business days

Shipping Method Options :

  • Priority Freight: 7–15 days (Air + Ground) — faster air delivery option at checkout.

All screen are shipped directly from our China headquarters.

DDP Term: Listed shipping methods are offered under DDP (Delivered Duty Paid), meaning customs clearance, duties, and taxes are included. If DDP service is not supported in the destination country, we will coordinate alternative terms (e.g., EXW / FOB) to ensure smooth delivery.

Specification

Part # HKaC-P3/7-LA HKaC-P3/7-MA HKaC-P3/7-HA
Pixel Pitch H:P3.9/W:P7.8mm H:P3.9/W:P7.8mm H:P3.9/W:P7.8mm
LED Type SMD2121 SMD1921 SMD1921
Scan 16 8 8
Viewing Distance >5Meters >5Meters >5Meters
Cabinet Type Aluminum Aluminum Aluminum
Cabinet Size 1000x1000x80mm 1000x1000x80mm 1000x1000x80mm
Cabinet Qty./㎡ 4 4 4
Cabinet Pixels 32768dots/㎡ 32768dots/㎡ 32768dots/㎡
Power Consumption Max.750W/㎡ Avg.240W/㎡ Max.800W/㎡ Avg.260W/㎡ Max.800W/㎡ Avg.260W/㎡
Input Voltage 100-240VAC 50/60HZ 100-240VAC 50/60HZ 100-240VAC 50/60HZ
Brightness 1500nits 3500nits 5500nits
Transparency Rate 60% 60% 60%
Refresh Rate 3840HZ 3840HZ 3840HZ
IP Protection Rating IP30 IP30 IP30
Mean Time Between Failures (MTBF) 10,000 Hours 10,000 Hours 10,000 Hours
Lifespan 100,000 Hours 100,000 Hours 100,000 Hours
Temperature -20℃~+40℃ -20℃~+40℃ -20℃~+40℃
Humidity 15%-90%RH 15%-90%RH 15%-90%RH
Installation Method Fixed / Hanging Fixed / Hanging Fixed / Hanging
Operating System Novastar/Colorlight Novastar/Colorlight Novastar/Colorlight
