Samsung / LG SMD5630 LED Strip Light, 12W per Meter, 60 LEDs/m, 12V DC, White PCB 10mm, 5m Roll (3000K / 4000K / 6000K, IP00 / IP67)

From $2,807.00
Color
IP Grade
Package Type & QTY.
$2,807.00
$2,807.00
Shipping calculated at checkout.
9999 in stock

Samsung / LG SMD5630 LED Strip Light, 12W per Meter, 60 LEDs/m, 12V DC, White PCB 10mm, 5m Roll (3000K / 4000K / 6000K, IP00 / IP67)

Package Included:

Version Package Included
1 Roll × 5 m (16.4 ft total) (Strip Only) 1 Roll × 5 m (16.4 ft) LED Strip Light Only, Do not include Power Supply and Controller
20 Rolls × 5 m (328 ft total) (Strip Only)
 20 Rolls × 5 m (328 ft total) LED Strip Light Only, Do not include Power Supply and Controller
100 Rolls × 5 m (1640 ft total) (Strip Only) 100 Rolls × 5 m (1640 ft total) LED Strip Light Only, Do not include Power Supply and Controller

Order & Logistics:

  • Lead Time: Typically 1–3 business days
  • Packing: Cardboard box, sealed with anti-static bag
  • Shipping:  7-12 days by AIR.

Strip Features:

  • Premium Samsung / LG SMD5630 Chips – High-quality LED chips ensure superior brightness, stable performance, and longer lifespan compared to standard LED strips.

  • High Luminous Efficiency – With 60 LEDs per meter and 12W power consumption, this strip delivers excellent light output while maintaining energy efficiency.

  • Multiple Color Temperatures – Available in 3000K Warm White, 4000K Neutral White, and 6000K Cool White to suit different lighting environments.

  • Flexible Installation & IP Options – Choose between IP00 (non-waterproof) for indoor applications or IP67 (waterproof silicone tube) for outdoor and damp areas.

  • Versatile Applications – Ideal for commercial lighting, retail displays, home decoration, under-cabinet lighting, signage, and architectural illumination.

Strip Specification

Item DC12V SAMSUNG/LG SMD5630-300 LED Strips 60LEDs Per Meter
Code HK-F5630X30-X
LED Type SAMSUNG/LC 5630 LED
LED QTY. 60LED/Meter
Wattage (max) <12Watt/Meter
Lumen Output Note1 1200LM/Meter
Cuttable Every 3LED per 2'' (5cm) can be cut
Length available Lengths within 5meters(16.4feet) and multiple of 2''(5cm)
Size(W*H/mm) 10*2   (for non-waterproof) ; IP67 with silicone tube be 12mm width.
Weight 0.15kgs/roll for non-waterproof; 0.25kgs/roll for IP65/IP67; 0.5kgs/roll for IP68.
Input Voltage 12V DC
Light Color Pure White(5500-6000K), Natural White(4000-4500K), Warm White(3000-3500K)
PCB color option White
PCB Backing Adhesive backing for Non-waterproof and waterproof IP65,extra rubber mounting clips provide for IP67 and IP68
Beam Angle 120°
Waterproof Type Non-waterproof(indoor use), Waterproof IP65, IP67, IP68
Dimming PWM dimmable   (more information please refer to different Dimmer applications)
Lead Single color strip has two contacts(V+,V-) and is Polarity Sensitive.
Pre-wiring 20cm(8'') Red-Black lead wire is pre-soldered at one end of the strip
Packing 5meters(16.4feet) per roll packed in a static bag
Note 1: When the strip make into a long string, a full roll we say, for there is voltage drop, so there final power consumption will be lower than the rated max data. Also the lumen output of a long string will be lower than the rated data per meter. There is an around 15-25% derated than the max. The shorter the strip, the output data will be closer to the rated.


Drawing per 5000mm for non-waterproof strip (1inch=25.4mm)

 How to power/control the strip

When choosing the transformer, the wattage to choose depends on how many pieces light strips it power.And when choosing the transformer, we suggest to use a bigger wattage transformer than the strip rated power to avoid full load working of the transformer. And a big power transformer do no harm to the strip but good for safety.

And a big power transformer do no harm to the strip but good for safety.

Below please find the connection diagram for Single Color Light Strip for reference.

a. Direct Powered by Transformer Run to AC Wall Outlet, On/Off controlled by a Wall Switch



b. Light strip On/Off/Brightness is controlled by  Dimmer (Wireless or Hardwire Type available)

#1 Typical connection for one Dimmer to control one string of light bars

#2 One Dimmer to control several strings of light bars by adding Amplifier, and powered by one or several transformers.

Note: The strips the Dimmer and Amplifier loaded with cannot exceed their rated max value. And in theory, you can add endless Amplifiers after the Dimmer.
